ACTIVES, EEE Components, SPECIFICATIONS / QPLs

Issue 38 of EUROPEAN PREFERRED PARTS LIST (EPPL)

  • Posted by Emilio Cano García
  • On August 12, 2019
  • 0

The changes in issue 38 of EUROPEAN PREFERRED PARTS LISTS (EPPL) are included in the DCR 1277 and detailed herein below:

New entries EPPL part 1:

  • Molded SMD Custom Magnetics based on types CCM and TO from Exxelias SAS (Site de d´Illange), included in the detail specifications ESCC 3201/011 and ESCC 3201/012. These components are listed in the ESCC QUALIFIED PART LIST (QPL).
wdt_ID Type Description Specification Package Manufacturer Qualification
1 Linear CCM Molded SMD Custom Magnetics 3201/011 See spec Exxelia SAS / F ESCC QML
4 Toroidal TO Molded SMD Custom Magnetics 3201/012 See spec Exxelia SAS / F ESCC QML

New entries EPPL part 2:

  • Ceramic High Voltage capacitors 200V-5kV from Exxelia SAS (Site de Chanteloup en Brie), included in the detail specifications ESCC 3001/039, ESCC 3001/040 and ESCC 3009/044.
wdt_ID Type Description Specification Package Manufacturer Qualification
1 TCF479S to TCF485S, TCK479S to TCK485S Ceramic, High Voltage 200V to 5kV, class 1 N2200 3001/039 SMD Exxelia SAS / F Not qualified
4 C480PS to C485PS, C480PLS to C485PLS, C480LS to C485LS, C480RS to C485RS Ceramic, High Voltage 200V to 5kV, class 1 N2200 3001/040 SMD Exxelia SAS / F Not qualified
7 C479S to C483S Ceramic, High Voltage 200V to 5kV, class 1 N2200 3009/044 SMD Exxelia SAS / F Not qualified
  • Organic polymer Tantalum capacitor based on type T584 from Kemet Electronics Portugal, included in the detail specification ESCC 3012/007.
wdt_ID Type Description Specification Package Manufacturer Qualification
1 T584 Multi-anode Organic polymer Tantalum 3012/007 SMD Kemet / Portugal Not qualified
  • Latch-Up Current Limiter 3DPM01682-2-SS from 3D Plus, included in the datasheet 3DPA-5090.
wdt_ID Type Description Specification Package Manufacturer Qualification
1 3DPM0168-2-SS Latch-Up Current Limiter 3DPA-5090-5 SOP-20 3D PLUS / F Not qualified
  • Chip fixed Film resistors JAXA WCR32-50-64 and JAXA SCR-16-20-32-35-50 from Hokuriku Electric, included in the detail specifications JAXA-QTS-2050/E302 and JAXA-QTS-2050/E301. These components are listed in the JAXA QUALIFED PART LIST (QPL).
wdt_ID Type Description Specification Package Manufacturer Qualification Remarks
1 JAXA WCR32- 50-64 Chip fixed film JAXA-QTS2050/E302 SMD Hokuriku Electric / Japan JAXA QML Case sizes: 3216, 5025, 6432
4 JAXA SCR-1620-32-3550 Chip Fixed film JAXA-QTS2050/E301 SMD Hokuriku Electric / Japan JAXA QML Case sizes: 1608, 2012 3216, 3225, 5025

Updates EPPL part 2:

  • The reference of SDRAM 4Gbit 3DSD4G08VS8292 from 3D PLUS have been changed to 3DSD4G08VS8613.
  • The datasheet and the package of 3DEE8M08VS8190 and 3DFN64G08VS8305 have been updated.
wdt_ID Type Description Specification Package Manufacturer Qualification
1 3DSD4G08VS8613 4Gb SDRAM 3DPA-5020 SOP58- 08 3D PLUS / F Not qualified
4 3DEE8M08VS8190 EEPROM 8Mbit 1Mx8 3DPA-1630 SOP40- 0.5 3D PLUS / F Not qualified
7 3DFN64G08VS8305 Flash NAND 8Gx8 3DPA-3420 SOP50- 0.5 3D PLUS / F Not qualified

About EUROPEAN PREFERRED PARTS LIST (EPPL)

The ESCC Executive publishes a list of components and technologies with the purpose to be useful to space hardware manufacturers and projects in their selection of EEE components.

Eligible components for listing in the EPPL are al EEE components categories as defined in ECSS-Q-ST-60. In addition, the following may also be listed in the EPPL: semiconductor die, semiconductor foundry processes, hybrid assembly processes, ESCC Capability Approvals and ESCC Technology Flow approvals.

The rules for establishing the list are defined in ESCC 12300.  The EPPL is made up of two parts:

  • Part 1: components which are fully qualified or evaluated to recognised space standards (e.g. ESCC) giving full or high confidence for space usage.
  • Part 2: components for which the potential capability to satisfy space application requirements has been demonstrated but which have not yet achieved space qualification.
