Murata has introduced the BLE32SN series of chip ferrite beads with the industry’s highest current ratings.
These are the world’s first chip-type noise suppression components with a 20A current rating. They will be used to provide noise suppression in circuits with large current flows, such as the battery charging systems and powertrains of electric vehicles (EVs) and industrial equipment.
Previously, no chip-type noise suppression filter could attain a 20A current rating. This meant multiple chips had to be mounted in parallel, adding to the bill-of-materials (BoM) costs and taking up valuable board real estate.
By specifying Murata’s BLE32SN series, a small number of chips will be required*, enabling space savings and weight reductions in implementations.
*When compared to using standard 10A-rated noise suppression chips.
By leveraging advanced structural simulation techniques, Murata engineers have successfully created a proprietary internal electrode design. This increases the electrode volume of these chips compared with those using a conventional arrangement, significantly lowering their DC resistance characteristics. Consequently, heat generation is reduced, so less thermal management is needed, allowing further cost and weight savings to be benefitted.
Murata’s BLE32SN series ferrite beads have a compact form factor, with 3.2mm × 2.5mm × 2mm dimensions. They are capable of supporting an operational temperature range of −55°C to +125°C or −55°C to +150°C, depending on customers’ application requirements.
